What is JZC500 concrete mixer?
JZC500 drum concrete mixer is a medium-sized self-falling mixing machine that operates with forward rotation for mixing and reverse rotation for discharging. Compared with the JZC350 model, the JZC500 offers a larger mixing capacity and higher production efficiency. It is suitable for mixing various types of plastic and semi-dry concrete. This machine is ideal for medium-sized construction projects, rural infrastructure development, and municipal engineering. It features a compact and reasonable structure, stable operation, and easy maintenance.
How does JZC500 concrete mixer work?
JZC500 mixer operates on the principle of “forward rotation for mixing, reverse rotation for discharging”:
During Mixing: The motor rotates in the forward direction, driving the drum to rotate clockwise. Aggregates, cement, water, and other raw materials are continuously lifted by the internal blades and fall freely inside the drum, creating a uniform mixing effect.
During Discharging: The motor reverses, causing the drum to rotate counterclockwise. The well-mixed concrete is guided to the discharge outlet and automatically unloaded.
Advantages & Features
Large Mixing Capacity: Mixes 0.5 cubic meters per batch, ideal for medium-scale construction.
Excellent Mixing Quality: The internal blades are arranged reasonably to ensure uniform mixing.
Compact and Efficient Structure: Small footprint, adaptable to various construction environments.
Easy and Reliable Operation: Centralized electric control panel for safe and easy operation.
Flexible Mobility: Some models are equipped with wheels for easy transportation and relocation.
Stable Operation: The whole machine is made with thickened steel plates and wear-resistant parts for extended service life.
Easy Maintenance: Key components are easy to replace, resulting in low maintenance costs.
Strong Compatibility: Can be integrated with batching machines and water pump systems to form a simple concrete batching plant.
Technical Specifications
| Model | JZC350 | JZC400 | JZC500 | |
|---|---|---|---|---|
| Discharging Capacity | 350L | 400L | 500L | |
| Loading Capacity | 560L | 640L | 800L | |
| Productivity | 10-14m³/h | 12-16m³/h | 18-20m³/h | |
| Power of mixing motor | 5.5kw | 5.5kw | 7.5-11kw | |
| Power of lifting motor | 4.5kw | 4.5kw | 5.5kw | |
| Power of water pump | 0.55kw | 0.55kw | 0.75kw | |
| Accuracy of water supply | Error≤2% | Error≤2% | Error≤2% | |
| Speed of mixing drum | 14r/min | 14r/min | 13r/min | |
| Size(L*W*H) | 2760✖2170✖3000mm | 2940✖2240✖2880mm | 3320✖2460✖3650mm | |
| Weight | 1950kg | 2160kg | 3100kg | |
Applications
Small and medium-sized construction projects (residential buildings, factories, warehouses)
Bridges, tunnels, highways, and municipal infrastructure
Rural roads, farmland irrigation, and livestock farm projects
Temporary construction sites or as auxiliary equipment for mobile batching plants
Various precast component factories and concrete product processing sites
Operation and Maintenance Guidelines
Before each use, check whether all fasteners are secure and the power supply is functioning properly.
Strictly control the feeding ratio to avoid overloading or dry mixing.
Never insert hands or tools into the mixing drum.
During operation, regularly inspect wear conditions of gears, bearings, and belts.
After each job, promptly clean the inner and outer surfaces of the drum to prevent concrete residue buildup.
Apply grease to lubrication points on a monthly basis.
Keep the electrical control cabinet protected from moisture and dust, and ensure grounding protection is in good condition.
Factory delivery of JZC500 Concrete Mixer
Delivery Time: For standard models, shipment is usually made within 3 to 7 working days after receiving the deposit, depending on the order quantity.
Packaging: Standard export packaging; key components such as the electric control box and reducer are packed in wooden cases to ensure safe transportation.
Shipping Methods: Land transportation or container sea shipping is available. Customers may choose their own logistics provider or request assistance from us.
Accessories Included: Product certificate of conformity, user manual, and a list of wearing parts are included with the shipment.
Pre-shipment Inspection: All equipment undergoes no-load testing and quality inspection before delivery to ensure stable performance and compliance with standards.
Service
Technical Guidance: Detailed installation videos and operation manuals are provided. If needed, engineers can offer remote video support or on-site assistance.
After-sales Warranty: The whole machine is covered by a 12-month warranty. Core components such as the reducer, motor, and electric control system are eligible for free replacement within the warranty period.
Spare Parts Supply: Long-term supply of original spare parts with quick response and timely delivery. Common wearing parts can be shipped together with the main machine.
Customer Training: Free training materials on operation and maintenance are provided to ensure that customer personnel can operate and maintain the equipment independently.
Customization Service: Loading method, motor voltage, appearance color, and logo can be customized according to customer requirements to achieve product personalization.
FAQ
1. What types of concrete can the JZC500 mix?
The JZC500 is suitable for mixing plastic concrete, flowable concrete, and some semi-dry hard concrete. It is not suitable for dry hard concrete.
2. Is there a diesel-powered version available?
Yes, TUOJIN Machinery offers a diesel-powered version of the JZC500, ideal for areas without electricity or for emergency construction projects.
3. What is the difference between the JZC500 and the JZC350?
The main differences lie in mixing capacity, production efficiency, overall dimensions, and power configuration. The JZC500 is better suited for larger construction projects with higher efficiency.
4. Are you a drum concrete mixer manufacturer?
Yes, we are a professional manufacturer of concrete mixers with over 30 years of production experience. Our products are exported to more than 30 countries.
5. Can I visit your cement mixer factory in China?
Of course. We warmly welcome visitors to our factory. Please contact us in advance to arrange a visit.
6. Do you offer OEM or customized drum mixers?
Yes, we offer OEM and customization services based on customer requirements such as color, logo, and technical specifications.
7. How can I get a quotation for your drum concrete mixer?
Please send us your requirements (model, quantity, power type, destination port), and we will send you a detailed quotation promptly.
